Some comments:
1- don’t use this names for your variables or window names, because they are used for some GiD standard windows
e.g, instead
global ParametricPriv
set w .gid.parametric
InitWindow $w “Create Parametric Line” ParametricWindowGeom
can use some like:
global PakkaPriv
set w .gid.pakka
InitWindow $w [= “Pakka window”] PakkaWindowGeom
2- It’s a bad idea to apply conditions directly to mesh entities, it’s better to apply to geometric entities and then generate the mesh.
and your if expression "if { [GiD_Info conditions] 5 } " is wrong:
- GiD_Info conditions need more arguments, read GiD help to know this and
- and you need to use some conditional, like if { [GiD_Info conditions …] == “5” } (read some manual about Tcl syntax)
I really don’t understand what are you trying to do.
you can ask GiD for the list of the nodes and its values with the condition Point-Force-Load
GiD_Info conditions Point-Force-Load mesh
and you can apply for example the values $fx $fy $fz to the nodes 1 and 2 (in mesh view) with
GiD_AssignData condition Point-Force-Load Nodes “$fx $fy $fz” “1 2”
or also with this through the GiD process loop:
GiD_Process Mescape Data Conditions AssignCond Point-Force-Load Change $fx $fy $fz 1 2
Regards
Enrique Escolano
----- Original Message -----
From: marco paccapelo
To: gidlist at gid.cimne.upc.edu
Sent: Thursday, June 19, 2008 2:12 PM
Subject: [GiDlist] Tcl script
Hi to all users of GiD
i’m trying to create a script in TCl language to assign force load to each node, but not to nodes with constrain ( named Vincoli in my case). it run well when it assign the conditions, but i dont find the way to found a comand to give true or false ( 0 or 1), or a list oh nodes with condition Vincoli assigned.
the *.tcl file is
GiDMenu::Create “Pakka-kun” PRE -2 =
GiDMenu::InsertOption “Pakka-kun” [list “Pacca”] 0 PRE “Pacca”
GiDMenu::RemoveOption “Help” [list “What is new”] PRE _
GiDMenu::UpdateMenus
proc Pacca {} {
global ParametricPriv
set w .gid.parametric
#creating the main window
InitWindow $w “Create Parametric Line” ParametricWindowGeom
#creating the widgets
frame $w.frmEquations
label $w.frmEquations.lx -text “X(t)”
entry $w.frmEquations.ex -relief sunken -width 15 -textvariable ParametricPriv(xt)
label $w.frmEquations.ly -text “Y(t)”
entry $w.frmEquations.ey -relief sunken -width 15 -textvariable ParametricPriv(yt)
label $w.frmEquations.lz -text “Z(t)”
entry $w.frmEquations.ez -relief sunken -width 15 -textvariable ParametricPriv(zt)
frame $w.frmButtons
button $w.frmButtons.btnApply -text “Assegna”
-command “Assign_loads $w”
-underline 0 -width 6
button $w.frmButtons.btnclose -text “Termina”
-command “destroy $w”
-underline 0 -width 6
#packing the widgets
grid $w.frmEquations -padx 5 -pady 5 -sticky ew
grid $w.frmEquations.lx $w.frmEquations.ex -sticky e
grid $w.frmEquations.ly $w.frmEquations.ey -sticky e
grid $w.frmEquations.lz $w.frmEquations.ez -sticky e
grid conf $w.frmEquations.ex $w.frmEquations.ey $w.frmEquations.ez -sticky ew
grid columnconf $w.frmEquations 1 -weight 1
grid $w.frmButtons -sticky ews -columnspan 7
grid $w.frmButtons.btnApply $w.frmButtons.btnclose -padx 5 -pady 6
grid columnconf $w “0” -weight 1
grid rowconfigure $w “3” -weight 1
}
proc Assign_loads { w } {
global ParametricPriv
set fx $ParametricPriv(xt)
set fy $ParametricPriv(yt)
set fz $ParametricPriv(zt)
set x [expr $fx]
set y [expr $fy]
set z [expr $fz]
.central.s process “Mescape Data Conditions AssignCond Point-Force-Load Change $fx $fy $fz”
for { set i 0 } { $i = [GiD_Info Mesh MaxNumNodes] } { incr i} {
if { [GiD_Info conditions] 5 } {
set nodo [expr $i]
.central.s process “$nodo”
} else {
}
}
.central.s process “escape”
.central.s process “Mescape”
.central.s process “redraw”
}
and the *.cnd
NUMBER: 1 CONDITION:Vincoli
CONDTYPE: over points
CONDMESHTYPE: over nodes
QUESTION:Tipologia:#CB#(Muro,Telaio)
VALUE:Telaio
DEPENDENCIES: (Muro,HIDE,Rotazione,#CURRENT#)
DEPENDENCIES: (Telaio,RESTORE,Rotazione,#CURRENT#)
QUESTION:Blocco_X:#CB#(1,0)
VALUE:1
QUESTION:Blocco_Y:#CB#(1,0)
VALUE: 1
QUESTION: Rotazione#CB#(1,0)
VALUE: 1
END CONDITION
NUMBER: 2 CONDITION: Point-Force-Load
CONDTYPE: over points
CONDMESHTYPE: over nodes
QUESTION:X-Force
VALUE:
QUESTION:Y-Force
VALUE:
QUESTION:z-Force
VALUE:
END CONDITION
I put the “if” in the proc of the tcl after the For only to try the comand if run with the for
I can also made a new for with a list of nodes, but i don’t find the comand on GiD manual to do that, to assign the point force load with “0 0 0”.
Thank for help and suggestions
Thanks for help
\
